Important safety information

Set up the device safel

Set up the device safelSet up the device safel

Set up the device safely

yy

y

Place the device on a flat and even surface- flip the battery

compartment cover and reinsert it to use it as a stand. The device can be hung on a nail

or screw by utilizing the hole on the back side of the case.

Ensure that:

• the device isn’t placed on a thick carpet or bed during operation ;

• no direct heat sources (i.e. radiators) influence the device;

• no direct sunlight reaches the device;

• contact with splashing or dripping water must be avoided (don’t place any items

filled with liquids, i.e. vases, onto or next to the device);

• the device doesn’t stand near magnetic fields (i.e. speakers);

• candles and other open flames must be kept away from this product at all times to

prevent the spread of fire

• no foreign objects penetrate the housing.

• the device is not placed near other devices that use the same frequency (433 MHz)

as this may interfere with signal reception.

Additional information about the outdoor sensor

Additional information about the outdoor sensorAdditional information about the outdoor sensor

Additional information about the outdoor sensor

Select a roofed area to setup your outdoor sensor. Do not let the sensor come into

contact with water or direct sunlight.

- Batteries

Insert the batteries/ rechargeable batteries in the correct polarity. Do not attempt to

recharge non-rechargeable batteries and under no circumstances throw them into fire.

Danger of explosion.

Do not use unequal batteries (old and new, Alkaline and carbon, etc.) simultaneously.

If you will not use the device for a long time, remove the batteries and store the device

in a dry and dust-free place. Improper use of batteries may cause an explosion or

leakage. If the batteries have leaked, use gloves and clean the device thoroughly with

a dry cloth.

Batteries/ rechargeable batteries can be life threatening when swallowed. Store the

batteries where they cannot be reached by small children. If a battery is swallowed,

medical aid must be sought immediately.



-

4

-

Setup

Remove the protective film from the display. Open the battery compartment on the

back side of the radio-controlled thermo-hygrometer and insert two 1.5V AAA

R03/LR03 batteries in the correct polarity. Close the battery compartment. The radio-

controlled thermo-hygrometer will now automatically measure the temperature and

humidity indoors. The measurement can be restarted by pressing RESET.

Now open the battery compartment of the radio sensor for outdoor temperature within

the next 3 minutes and insert two 1.5V AA R6/LR6 batteries in the correct polarity.

Close the battery compartment. The sensor will blink when the batteries are inserted. If

the reception is adequate, the radio-controlled thermo-hygrometer will receive the

signal within the next minutes and display the outdoor temperature. Press the TX-button

within the battery compartment of the sensor to restart sensor.

Temperature display

Press IN/OUT to select the indoor or outdoor temperature display. If using more than

one sensor (up to 3), press CHANNEL to select a sensor.

If reception is lost, the radio-controlled thermo-hygrometer will continue to display the

last recorded temperature. Press RESET to start a new reception attempt and then press

the TX-button within the battery compartment of the outdoor sensor.

The device shows the lowest and highest measured temperature and humidity under

MIN-MAX.

Channel selection

If using more than one sensor, press CHANNEL to select a sensor. To display the data

from the sensor that was included with your radio-controlled thermo-hygrometer, select

channel 1 ("CH1") on the display.



-

5

-

Alarm features

In unfavourable conditions your radio-controlled thermo-hygrometer will show different

symbols at the top of the display and emit an audible warning. The audible warning

can be activated by pressing the alarm button on the top of the case. When the alarm

is activated the bell symbol will appear on the display.

risk

riskrisk

risk

increased risk

increased riskincreased risk

increased risk

description

descriptiondescription

description

Low humidity / temperature

Low humidity / temperatureLow humidity / temperature

Low humidity / temperature

At low humidity the mucous membranes are drier

and therefore more susceptible to infection.

(face blinks)

High humidity / temperature

High humidity / temperatureHigh humidity / temperature

High humidity / temperature

Increased risk of mould caused by high humidity.

High temperature / humidity

High temperature / humidityHigh temperature / humidity

High temperature / humidity

High temperatures strain your body. Ideally, the

indoor temperature should not rise too much,

even at high outdoor temperatures.

(no audible warning)

Large change in outdoor temperature

Large change in outdoor temperatureLarge change in outdoor temperature

Large change in outdoor temperature (±5°C

(±5°C (±5°C

(±5°C

in

in in

in one hour

one hourone hour

one hour)

))

)

Your radio-controlled thermo-hygrometer warns

you of large changes in the outdoor

temperature.

Comfort display

In favourable indoor climate conditions the comfort symbol will appear on the display.



-

6

-

Feature chart 0%-54% humidity

LO

10

%

15

%

20

%

25

%

30

%

35

%

40

%

45

%

50

%

0

°C

5

°C

10

°C

15

°C

20

°C

25

°C

30

°C

35

°C

40

°C

45

°C

50

°C
