Návod Bontempi 24 1410 Gitara

Návod

4

SWITCH ON/OFF

To switch on the instrument move selector

a

to ON. To

switch the instrument off move the same selector to

OFF.

If the instrument is not used it switches itself off after a

few minutes. Press any key to reactivate it .

b

Wireless function activation/Sound effects

c

Select 2 demosongs + 2 rhythms

d

Volume

e

Selection of 8 demosongs

f

Headset microphone socket

g

Shoulder strap

h

Cords to play 8 demo songs

CONNECTING THE MICROPHONE HEADSET

(supplied)

Insert the microphone plug into the socket

f

.

Warning!: To avoid “feed back” please place the

microphone as far from the speaker as possible. Wear the

headset microphone as indicated in the figure and

position the microphone as near to your mouth as

possible.

HOW TO PLAY

This keyboard has 10 demosongs. Press the

DEMOSONGS

e

button in sequence to choose 8

demosongs. By repeatedly tapping at least 2 chords

h

with your fingers, the demo is played, note after note.

N.B.: You may find it difficult to execute this function if

the skin on your fingers is dry and chafed.

By pressing the DEMO/RHYTHMS button

c

you can

listen to 2 demos and 2 rhythms.

By pressing the SOUND EFFECTS button

b

you can

listen to 3 sound effects.

WIRELESS CONNECTION

An external audio source can be connected

(smartphone, tablet, PC, etc. - not supplied) as follows:

1. Hold down the WIRELESS button

b

for a few seconds

until you hear an audible sound.

2. Turn on Bluetooth on your smartphone, tablet, etc.

and select “Bontempi 1410” to pair it with your

guitar: an audible sound indicates that it is connected.

3. Search through the playlist on your smartphone or

computer for a song and play it. You can listen to the

song through the speaker on your guitar.

VOLUME CONTROL

Adjust volume to desired level by using the VOLUME

+/– button d.

POWER SUPPLY

Use a screwdriver to open

the battery compartment.

Insert 3 x 1.5 V batteries

R6/AA (not supplied),

ensuring correct polarity

(+/–). Re-fit battery cover.

Replace batteries when

the quality of sound becomes bad. Use alkaline batteries

to obtain a longer duration.

ATTENTION - BATTERY CARE:

Non-rechargeable batteries are NOT to be recharged. • Rechargeable batteries

must be removed from the product before being charged. • Rechargeable

batteries are only to be charged under adult supervision. • Different types of

batteries or new and old batteries are not to be mixed. • Use only batteries of

the same or equivalent type. • Batteries are to be inserted with correct

polarity. • Remove exhausted batteries to prevent leakage. • Do not short

circuit supply terminals. • Remove batteries during long periods of non-use.

WASTE DISPOSAL STANDARDS

For information regarding the disposal of the items mentioned here below,

please refer to Council Administration office regarding specialised waste

collection centres.

1. DISPOSAL OF BATTERIES: Protect the environment by

disposing of batteries in the special containers provided

for this use.

2. PACKAGING DISPOSAL: Take the paper, cardboard and corrugated board to

the appropriate waste collection centres. Plastic material must be placed in

the relevant collection containers.

The symbols indicating the various types of plastic are:

Key for the different types of plastic materials:

PET= Polyethylene terephtalate • PE= Polyethylene, code 02 for PE-HD, 04

for PE-LD • PVC =Polyvinyl chloride • PP= Polypropylene • PS= Polystyrene,

Polystyrene foam • O= Other polymers (ABS, Laminates, etc.)

3. DISPOSING OF ELECTRICAL APPLIANCES: The wheelie bin

symbol with a cross indicates that the product must not be

disposed of in the domestic waste at the end of its useful life.

Instead, it should be taken to your nearest designated collection

point or recycling facility. Alternatively, check with your retailer and return

the product when buying a replacement, on a one-to-one basis or as free of

charge in case the size is smaller than 25 cm. Appropriate disposal promotes

the recycling of parts and materials, as well as helping to protect the

environment and human health. Under current legislation, strict penalties

are enforced against those disposing of products illegally. For more

information about the collection of special waste, contact your Local

Authority.

01

PET

02

PE

03

PVC

05

PP

06

PS

07

O

R6/AA 1.5V

R6/AA 1.5V

R6/AA 1.5V

R6/AA 1.5V

R6/AA 1.5V

R6/AA 1.5V

E N G L I S H
