AUX function

To use the AUX function, connect your audio device to the AUX-IN jack (20) with a 3.5 mm AUX cable. Then move

the function switch to the "AM/FM/SW/BT" position. "AUX" will be displayed on the LCD screen. The product will

start playing music from the connected audio device.

- Turn the volume knob (16) to adjust the volume.

RADIO OPERATION

Move the function switch to the SW or AM or FM position (11) to pick up the desired frequency.

Turn the volume knob to adjust the volume level. Turn the tuning knob (17) to select the desired frequency.

Note: Adjust the product direction when reception is interfered with when using the AM function. Adjust the direction

of the FM antenna (4) on the product when reception is interfered with when using the FM function.

SD CARD PLAYBACK

1. Slide the function switch to BT/TF position, long press the "play/pause/BT/TF" button to select TF mode, the LCD

will show "TF, insert the SD memory card into the TF port, after a few seconds, the unit will automatically play the

first song from the SD card,

2. Press PAUSE/PLAY button to pause playback, press again to resume playback,

3. Press the Next button to advance to the next track.

4. Press Previous to go to the previous track.

5. If you need to turn off the power, simply move the function button to the OFF position.

SOS ALARM FUNCTION

To use the SOS function, press and hold the SOS button (9), the speaker will alert loudly and the LED flashlight will

flash, press this button briefly to turn off the function.

Specifications:

FM radio: 87.5-108MHz

AM radio: 522-1620KHz

SW radio: 2.3-22MHz

Bluetooth: Version 5.0

Speaker: φ40mm, 8Ω 2W

Display: LCD screen

Battery: 3.7V 4000mAh rechargeable battery

Charging input: 5V DC 2A

USB output: 5V DC 1A (max)

LED flashlight: 3W (white)

Ambient light: 1W (warm white)

Antenna: Maximum length 26 cm

Device size: 181 X72 X82.1 mm

Weight of the item: 450g

Material: ABS plastic

For the sake of the environment. Information about waste electrical and electronic equipment In accordance with Article 13(1) and (2) of

the Law of September 11, 2015 on waste electrical and electronic equipment, we inform you about the proper handling of waste electrical

and electronic equipment:

1. It is forbidden to place waste electrical and electronic equipment together with other waste - this is confirmed by marking in the form of

a "crossed out basket", ordering selective collection of this type of waste.

2. Electrical and electronic equipment may contain hazardous substances, mixtures and components that, when released into the

environment, can cause serious danger to the health and life of humans and living organisms. They can lead to numerous health ailments,

such as vision, hearing and speech disorders, and can also damage the kidneys, liver and heart, and cause skin diseases. Harmful substances,

can also have adverse effects on the respiratory and reproductive systems and lead to cancerous changes. Consumption of plants growing

on contaminated soils, and products made from them, can risk the aforementioned health effects.

3. Waste electrical and electronic equipment should be handed over only to authorized collection points, a list of which should be included

on each Municipality's website.

4. The household plays an important role, in contributing to the reuse and recovery, including recycling, of waste equipment. It also plays a

key role in the waste electrical and electronic equipment management system due to the possibility of direct delivery to authorized

collection points and the elimination of undesirable social habits resulting in leaving waste equipment in places not intended for it.

In addition, Donate waste electrical and electronic equipment at the point of delivery. A distributor, when supplying equipment intended

for households to a purchaser, is obliged to take back used household equipment free of charge at the place of delivery of such equipment,

provided the used equipment is of the same type and performed the same functions as the supplied equipment.
