10

GB

Assembling the Grass Box

D

1. Connect the two pieces of the

collection box (4).

2. Connect the handle (15) in one

of the two pieces of the collec-

tion box (16). The arrow mark-

ings on the handle (15) and at

the top of the grass grass (16)

show the alignment of the han-

dle (15).

Do not work with the lawn mower

without impact protection. There is

a risk of injury.

We recommend always using the

grass box when working with the

lawn mower, otherwise the mow-

ing result may be signicantly im-

paired.

Operation

Hanging On / Removing the

Grass Box

E

1. To hang on the grass box (4),

lift the collision guard (7) and

hang on the grass box. Fold the

collision guard (7) onto the grass

box (4). It holds the grass box in

the correct position.

2. To remove the grass box (4),

lift the collision guard (7) and

detach the grass box. Fold the

collision guard (7) back onto the

mower housing (6).

The level gauge (

D

20) is located on the

side of the grass catcher (4).

Flap (

D

20) open:

grass catcher (4) empty

Flap (

D

20) closed:

grass catcher (4) full

Adjusting the Cut Height

Switch off the equipment, discon-

nect the plug and wait for the blade

to stop. There is a risk of injury.

The lawn mower can be set to the follow-

ing cut heights by means of three position

changes of the front and rear wheels, ad-

justing the individual wheels:

The single wheel adjustment has

always to be at least at one axis.

60 mm - Tall cutting height

40 mm - Medium cutting height

20 mm - Short cutting height

F

1. Unscrew the wheels (5).

2. Screw the wheels (5) back on in

the desired position. The single

wheel adjustment has always to

be at least at one axis

The correct height is around 25 – 40 mm

for a decorative lawn and around 30 – 60

mm for a used lawn.

A higher cut height should be se-

lected for the rst cut of the season.

Observe the noise protection and

local regulations.

Switching On and Off

1. Insert the power cable plug into

the socket (

A

9) on the curved

handle (

A

1).

2. To relieve the strain, form a loop

with the end of the power cable

and hang this into the strain reli-

ef (11). See the diagram

.

3. Connect the equipment to the

power supply.

4. Before switching on, ensure that

the equipment is not in contact

with any objects.
