Návod JBL Club 4020 Reproduktor do auta
Potrebujete príručku pre svoj JBL Club 4020 Reproduktor do auta? Nižšie si môžete bezplatne prezrieť a stiahnuť príručku vo formáte PDF v slovenskom jazyku. Tento produkt má momentálne 0 často kladené otázky, 0 komentárov a má 0 hlasov. Ak toto nie je manuál, ktorý chcete, kontaktujte nás.
Je váš výrobok pokazený a nepodarilo sa vám problém odstrániť pomocou pokynov v návode? Prejdite na portál Repair Café, kde nájdete bezplatné servisné služby.
Návod
Loading…
Торговая марка : JBL
Назначение товара : Автомобильная акустическая система
Изготовитель : Харман Интернешнл Индастриз Инкорпорейтед, США, 06901 Коннектикут, г.Стэмфорд, Атлантик Стрит 400, офис 1500
Страна происхождения : Вьетнам
Импортер в Россию : OOO “ХАРМАН РУС СиАйЭс“, РОССИЯ, 127018, г.МОСКВА, УЛ. ДВИНЦЕВ, Д.12, КОРПУС 1
Гарантийный период : 1 год
Информация о сервисных центрах : www.harman.com/ru тел. +7-800-700-0467
Срок службы : 5 лет
Срок хранения : не ограничен
Условия хранения : Cтандартные при нормальных значениях климатических факторов внешней среды
Номер документа соответствия : Товар не подлежит обязательной сертификации
Дата производства : Дата изготовления устройства определяется по двум буквенным обозначениям из второй группы символов серийного номера изделия, следующих после
разделительного знака «-». Кодировка соответствует порядку букв латинского алфавита, начиная с января 2010 года: 000000-MY0000000, где «M» - месяц производства
(А - январь, B - февраль, C - март и т.д.) и «Y» - год производства (
A - 2010, B - 2011, C - 2012 и т.д.).
仕様書 CLUB 6520 CLUB 9630 CLUB 3020 CLUB 4020 CLUB 5020 CLUB 6420 CLUB 8620 CLUB 5000C CLUB 6500C CLUB 9600C CLUB 750T
型
連続許容入力 50W 80W 20W 30W 40W 35W 55W 55W 60W 90W 45W
ピーク許容入力 150W 240W 60W 90W 120W 105W 165W 165W 180W 270W 135W
周波数特性 55Hz-20KHz 50Hz-20KHz 90Hz - 20kHz 75Hz - 20kHz 75Hz - 20kHz 75Hz-20KHz 65Hz - 20kHz 70Hz-20KHz 55Hz - 20kHz 50Hz - 20kHz 3kHz - 20kHz
公称インピーダンス 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms
感度(2.83V/1m) 92dB 93dB 89dB 90dB 91dB 91dB 93dB 91dB 92dB 93dB 92dB
外部直径 6-1/4" (158mm)
9-5/16" X 6-7/16" 3-7/16" (87mm) 4-1/16" (102.4mm) 5-1/8" (129mm) 6-3/16" X 3-15/16" 8-11/16" X 5-5/8" 5-1/8" (129mm) 6-1/4" (158mm) 9-5/16" X 6-7/16 2-1/4" (56mm)
(236.5mm X 163mm) (157mm X 99.5mm) (220mm X 142.2mm) (236.5mm X 163mm)
取り付けカットアウト直径 4-7/8" (123.4mm) 8-1/2" X 5-3/4" 3" (75.5mm) 3-11/16" (92.1mm) 4-1/2" (113.6mm) 5-9/16" X 3-3/8" 7-1/4" X 5" 4-1/2" (113.6mm) 4-7/8" (123.4mm) 8-1/2" X 5-3/4" 1-5/8" (40mm)
(214.6mm X 144.6mm) (140.4mm X 85.1mm) (182.6mm X 125.6mm) (214.6mm X 144.6mm)
トータルの寸法 2-1/4" (56.4mm) 3-11/16" (92.7mm) 1-7/8" (47.6mm) 2-1/8" (52.6mm) 2-1/16" (52mm) 2" (50.7mm) 2-11/16" (67.3mm) 2-1/16" (52mm) 2-1/4" (56.4mm) 3-1/2" (88mm) 1-7/16" (36.1mm)
埋め込み寸法 1-13/16" (44.6mm) 3-1/8" (77.8mm) 1-7/16" (35.7mm) 1-7/8" (46.8mm) 1-13/16" (45mm) 1-3/4" (43.9mm) 2-5/16" (58.5mm) 1-13/16" (45mm) 1-13/16" (44.6mm) 3-1/8" (77.8mm) 13/16" (20mm)
6-1/2インチ(160mm)
同軸カースピーカー
3-1/2インチ(87mm)
同軸カースピーカー
4インチ(100mm)
同軸カースピーカー
5-1/4インチ(130mm)
同軸カースピーカー
4インチ×6インチ
同軸カースピーカー
6インチ×8インチ
同軸カースピーカー
5-1/4インチ(130mm)
コンポーネント･スピー
カーシステム
6-1/2インチ(160mm)
コンポーネント･スピー
カーシステム
6インチx9インチ･コン
ポーネント･スピーカー
システム
3/4インチ(19mm)コン
ポーネントツイーター
6インチ ×9インチ3ウ
ェイ･カースピーカー
사양 CLUB 6520 CLUB 9630 CLUB 3020 CLUB 4020 CLUB 5020 CLUB 6420 CLUB 8620 CLUB 5000C CLUB 6500C CLUB 9600C CLUB 750T
타입
연속 파워 핸들링 50W 80W 20W 30W 40W 35W 55W 55W 60W 90W 45W
최대 파워 핸들링 150W 240W 60W 90W 120W 105W 165W 165W 180W 270W 135W
주파수 응답 55Hz-20KHz 50Hz-20KHz 90Hz - 20kHz 75Hz - 20kHz 75Hz - 20kHz 75Hz-20KHz 65Hz - 20kHz 70Hz-20KHz 55Hz - 20kHz 50Hz - 20kHz 3kHz - 20kHz
공칭 임피던스 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms
민감도(2.83V/1m) 92dB 93dB 89dB 90dB 91dB 91dB 93dB 91dB 92dB 93dB 92dB
외경 6-1/4" (158mm)
9-5/16" X 6-7/16" 3-7/16" (87mm) 4-1/16" (102.4mm) 5-1/8" (129mm) 6-3/16" X 3-15/16" 8-11/16" X 5-5/8" 5-1/8" (129mm) 6-1/4" (158mm) 9-5/16" X 6-7/16 2-1/4" (56mm)
(236.5mm X 163mm) (157mm X 99.5mm) (220mm X 142.2mm) (236.5mm X 163mm)
장착 컷아웃 직경 4-7/8" (123.4mm) 8-1/2" X 5-3/4" 3" (75.5mm) 3-11/16" (92.1mm) 4-1/2" (113.6mm) 5-9/16" X 3-3/8" 7-1/4" X 5" 4-1/2" (113.6mm) 4-7/8" (123.4mm) 8-1/2" X 5-3/4" 1-5/8" (40mm)
(214.6mm X 144.6mm) (140.4mm X 85.1mm) (182.6mm X 125.6mm) (214.6mm X 144.6mm)
총깊이 2-1/4" (56.4mm) 3-11/16" (92.7mm) 1-7/8" (47.6mm) 2-1/8" (52.6mm) 2-1/16" (52mm) 2" (50.7mm) 2-11/16" (67.3mm) 2-1/16" (52mm) 2-1/4" (56.4mm) 3-1/2" (88mm) 1-7/16" (36.1mm)
장착 깊이 1-13/16" (44.6mm) 3-1/8" (77.8mm) 1-7/16" (35.7mm) 1-7/8" (46.8mm) 1-13/16" (45mm) 1-3/4" (43.9mm) 2-5/16" (58.5mm) 1-13/16" (45mm) 1-13/16" (44.6mm) 3-1/8" (77.8mm) 13/16" (20mm)
6-1/2인치(160mm)
동축 카 스피커
3-1/2인치(87mm)
동축 카 스피커
4인치(100mm)
동축 카 스피커
5-1/4인치(130mm)
동축 카 스피커
4 x 6인치 동축 카
스피커
6 x 8인치 동축 카
스피커
5-1/4인치(130mm)
컴포넌트 스피커
시스템
6-1/2인치(160mm)
컴포넌트 스피커
시스템
6 x 9인치 컴포넌트
스피커 시스템
3/4인치(19mm)
컴포넌트 트위터
6 x 9인치 3방향
카 스피커
Japanese
Korean
规格 CLUB 6520 CLUB 9630 CLUB 3020 CLUB 4020 CLUB 5020 CLUB 6420 CLUB 8620 CLUB 5000C CLUB 6500C CLUB 9600C CLUB 750T
类型
连续功率承受能力 50W 80W 20W 30W 40W 35W 55W 55W 60W 90W 45W
峰值功率承受能力 150W 240W 60W 90W 120W 105W 165W 165W 180W 270W 135W
频率响应 55Hz-20KHz 50Hz-20KHz 90Hz - 20kHz 75Hz - 20kHz 75Hz - 20kHz 75Hz-20KHz 65Hz - 20kHz 70Hz-20KHz 55Hz - 20kHz 50Hz - 20kHz 3kHz - 20kHz
标称阻抗 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms
灵敏度 (2.83V/1m) 92dB 93dB 89dB 90dB 91dB 91dB 93dB 91dB 92dB 93dB 92dB
外径 6-1/4" (158mm) 9-5/16" X 6-7/16" 3-7/16" (87mm) 4-1/16" (102.4mm) 5-1/8" (129mm) 6-3/16" X 3-15/16" 8-11/16" X 5-5/8" 5-1/8" (129mm) 6-1/4" (158mm) 9-5/16" X 6-7/16 2-1/4" (56mm)
(236.5mm X 163mm) (157mm X 99.5mm) (220mm X 142.2mm) (236.5mm X 163mm)
安装切口直径 4-7/8" (123.4mm) 8-1/2" X 5-3/4" 3" (75.5mm) 3-11/16" (92.1mm) 4-1/2" (113.6mm) 5-9/16" X 3-3/8" 7-1/4" X 5" 4-1/2" (113.6mm) 4-7/8" (123.4mm) 8-1/2" X 5-3/4" 1-5/8" (40mm)
(214.6mm X 144.6mm) (140.4mm X 85.1mm) (182.6mm X 125.6mm) (214.6mm X 144.6mm)
总深度 2-1/4" (56.4mm) 3-11/16" (92.7mm) 1-7/8" (47.6mm) 2-1/8" (52.6mm) 2-1/16" (52mm) 2" (50.7mm) 2-11/16" (67.3mm) 2-1/16" (52mm) 2-1/4" (56.4mm) 3-1/2" (88mm) 1-7/16" (36.1mm)
安装深度 1-13/16" (44.6mm) 3-1/8" (77.8mm) 1-7/16" (35.7mm) 1-7/8" (46.8mm) 1-13/16" (45mm) 1-3/4" (43.9mm) 2-5/16" (58.5mm) 1-13/16" (45mm) 1-13/16" (44.6mm) 3-1/8" (77.8mm) 13/16" (20mm)
6-1/2" (160mm)
同轴车载扬声器
3-1/2" (87mm) 同
轴车载扬声器
4" (100mm) 同轴
车载扬声器
5-1/4" (130mm)
同轴车载扬声器
4" x 6" 同轴车载扬
声器
6" x 8" 同轴车载扬
声器
5-1/4" (130mm)
分体式扬声器系统
6-1/2" (160mm)
分体式扬声器系统
6" x 9" 分体式扬声
器系统
3/4" (19mm) 分体
式高音扬声器
6" x 9" 三分频车载
扬声器
DANE TECHNICZNE CLUB 6520 CLUB 9630 CLUB 3020 CLUB 4020 CLUB 5020 CLUB 6420 CLUB 8620 CLUB 5000C CLUB 6500C CLUB 9600C CLUB 750T
Rodzaj
Moc (ciągła)
50W 80W 20W 30W 40W 35W 55W 55W 60W 90W 45W
Moc (szczytowa)
150W 240W 60W 90W 120W 105W 165W 165W 180W 270W 135W
Pasmo przenoszenia
55Hz-20KHz 50Hz-20KHz 90Hz - 20kHz 75Hz - 20kHz 75Hz - 20kHz 75Hz-20KHz 65Hz - 20kHz 70Hz-20KHz 55Hz - 20kHz 50Hz - 20kHz 3kHz - 20kHz
Impedancja znamionowa
3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms
Efektywnosc (przy 2,83 V/1m) 92dB 93dB 89dB 90dB 91dB 91dB 93dB 91dB 92dB 93dB 92dB
Średnica zewnętrzna
6-1/4" (158mm) 9-5/16" X 6-7/16" 3-7/16" (87mm) 4-1/16" (102.4mm) 5-1/8" (129mm) 6-3/16" X 3-15/16" 8-11/16" X 5-5/8" 5-1/8" (129mm) 6-1/4" (158mm) 9-5/16" X 6-7/16 2-1/4" (56mm)
(236.5mm X 163mm) (157mm X 99.5mm) (220mm X 142.2mm) (236.5mm X 163mm)
Średnica wnęki do montażu
4-7/8" (123.4mm) 8-1/2" X 5-3/4" 3" (75.5mm) 3-11/16" (92.1mm) 4-1/2" (113.6mm) 5-9/16" X 3-3/8" 7-1/4" X 5" 4-1/2" (113.6mm) 4-7/8" (123.4mm) 8-1/2" X 5-3/4" 1-5/8" (40mm)
(214.6mm X 144.6mm) (140.4mm X 85.1mm) (182.6mm X 125.6mm) (214.6mm X 144.6mm)
Całkowita głębokość
2-1/4" (56.4mm) 3-11/16" (92.7mm) 1-7/8" (47.6mm) 2-1/8" (52.6mm) 2-1/16" (52mm) 2" (50.7mm) 2-11/16" (67.3mm) 2-1/16" (52mm) 2-1/4" (56.4mm) 3-1/2" (88mm) 1-7/16" (36.1mm)
Głębokość montażowa
1-13/16" (44.6mm) 3-1/8" (77.8mm) 1-7/16" (35.7mm) 1-7/8" (46.8mm) 1-13/16" (45mm) 1-3/4" (43.9mm) 2-5/16" (58.5mm) 1-13/16" (45mm) 1-13/16" (44.6mm) 3-1/8" (77.8mm) 13/16" (20mm)
Polish
Simplified
Chinese
współosiowy głośnik
samochodowy 160
mm (6-1/2”)
trójdrożny głośnik
samochodowy
6" x 9"
współosiowy głośnik
samochodowy
87 mm (3-1/2”)
współosiowy głośnik
samochodowy
100 mm (4”)
współosiowy głośnik
samochodowy
130 mm (5-1/4”)
współosiowy głośnik
samochodowy
4" x 6"
współosiowy głośnik
samochodowy
6" x 8"
zestaw głośnikowy
130 mm (5-1/4”)
zestaw głośnikowy
160 mm (6-1/2”)
zestaw głośnikowy
6" x 9"
głośnik
wysokotonowy
19 mm (3/4”)
CLUB 6520 CLUB 9630 CLUB 3020 CLUB 4020 CLUB 5020 CLUB 6420 CLUB 8620 CLUB 5000C CLUB 6500C CLUB 9600C CLUB 750T
Ти п
Постоянная мощность
50W 80W 20W 30W 40W 35W 55W 55W 60W 90W 45W
Пиковая мощность
150W 240W 60W 90W 120W 105W 165W 165W 180W 270W 135W
Эффективный рабочий
диапазон частот
55Hz-20KHz 50Hz-20KHz 90Hz - 20kHz 75Hz - 20kHz 75Hz - 20kHz 75Hz-20KHz 65Hz - 20kHz 70Hz-20KHz 55Hz - 20kHz 50Hz - 20kHz 3kHz - 20kHz
Номинальный импеданс
3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms
Чувствительность (2,83 В/1м)
92dB 93dB 89dB 90dB 91dB 91dB 93dB 91dB 92dB 93dB 92dB
Внешний диаметр
6-1/4" (158mm) 9-5/16" X 6-7/16" 3-7/16" (87mm) 4-1/16" (102.4mm) 5-1/8" (129mm) 6-3/16" X 3-15/16" 8-11/16" X 5-5/8" 5-1/8" (129mm) 6-1/4" (158mm) 9-5/16" X 6-7/16 2-1/4" (56mm)
(236.5mm X 163mm)
(157mm X 99.5mm) (220mm X 142.2mm) (236.5mm X 163mm)
Диаметр выемки для
4-7/8" (123.4mm) 8-1/2" X 5-3/4" 3" (75.5mm) 3-11/16" (92.1mm) 4-1/2" (113.6mm) 5-9/16" X 3-3/8" 7-1/4" X 5" 4-1/2" (113.6mm) 4-7/8" (123.4mm) 8-1/2" X 5-3/4" 1-5/8" (40mm)
установки
(214.6mm X 144.6mm) (140.4mm X 85.1mm) (182.6mm X 125.6mm) (214.6mm X 144.6mm)
Общая глубина
2-1/4" (56.4mm) 3-11/16" (92.7mm) 1-7/8" (47.6mm) 2-1/8" (52.6mm) 2-1/16" (52mm) 2" (50.7mm) 2-11/16" (67.3mm) 2-1/16" (52mm) 2-1/4" (56.4mm) 3-1/2" (88mm) 1-7/16" (36.1mm)
Глубина установки
1-13/16" (44.6mm) 3-1/8" (77.8mm) 1-7/16" (35.7mm) 1-7/8" (46.8mm) 1-13/16" (45mm) 1-3/4" (43.9mm) 2-5/16" (58.5mm) 1-13/16" (45mm) 1-13/16" (44.6mm) 3-1/8" (77.8mm) 13/16" (20mm)
ТЕХНИЧЕСКИЕ
ХАРАКТЕРИСТИКИ
Коаксиальный автомоб-
ильный динамик размером
160 мм (6½ дюйма)
Коаксиальный автомоб-
ильный динамик размером
87 мм (3½ дюйма)
Коаксиальный
автомобильный динамик
размером 100 мм (4 дюйма)
Коаксиальный автомоб-
ильный динамик размером
130 мм (5¼ дюйма)
Коаксиальный
автомобильный динамик
размером 4 x 6 дюймов
Коаксиальный
автомобильный динамик
размером 6 x 8 дюймов
Компонентная система
динамиков размером 130
мм (5¼ дюйма)
Компонентная система
динамиков размером 160
мм (6½ дюйма)
Компонентная система
динамиков размером 6 x 9
дюймов
Компонентный
высокочастотный динамик
размером 19 мм (¾ дюйма)
Трехрежимный
автомобильный динамик
размером6x9дюймов
SPECIFIKATIONER CLUB 6520 CLUB 9630 CLUB 3020 CLUB 4020 CLUB 5020 CLUB 6420 CLUB 8620 CLUB 5000C CLUB 6500C CLUB 9600C CLUB 750T
Type
Kontinuerlig effekthåndtering 50W 80W 20W 30W 40W 35W 55W 55W 60W 90W 45W
Spidsbelastning 150W 240W 60W 90W 120W 105W 165W 165W 180W 270W 135W
Frekvensområde 55Hz-20KHz 50Hz-20KHz 90Hz - 20kHz 75Hz - 20kHz 75Hz - 20kHz 75Hz-20KHz 65Hz - 20kHz 70Hz-20KHz 55Hz - 20kHz 50Hz - 20kHz 3kHz - 20kHz
Nominel impedans 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms
Følsomhed (2,83 V/1m) 92dB 93dB 89dB 90dB 91dB 91dB 93dB 91dB 92dB 93dB 92dB
Udvendig diameter 6-1/4" (158mm) 9-5/16" X 6-7/16" 3-7/16" (87mm) 4-1/16" (102.4mm) 5-1/8" (129mm) 6-3/16" X 3-15/16" 8-11/16" X 5-5/8" 5-1/8" (129mm) 6-1/4" (158mm) 9-5/16" X 6-7/16 2-1/4" (56mm)
(236.5mm X 163mm) (157mm X 99.5mm) (220mm X 142.2mm) (236.5mm X 163mm)
Diameter for 4-7/8" (123.4mm) 8-1/2" X 5-3/4" 3" (75.5mm) 3-11/16" (92.1mm) 4-1/2" (113.6mm) 5-9/16" X 3-3/8" 7-1/4" X 5" 4-1/2" (113.6mm) 4-7/8" (123.4mm) 8-1/2" X 5-3/4" 1-5/8" (40mm)
monteringsudskæring (214.6mm X 144.6mm) (140.4mm X 85.1mm) (182.6mm X 125.6mm) (214.6mm X 144.6mm)
Samlet dybde 2-1/4" (56.4mm) 3-11/16" (92.7mm) 1-7/8" (47.6mm) 2-1/8" (52.6mm) 2-1/16" (52mm) 2" (50.7mm) 2-11/16" (67.3mm) 2-1/16" (52mm) 2-1/4" (56.4mm) 3-1/2" (88mm) 1-7/16" (36.1mm)
Monteringsdybde 1-13/16" (44.6mm) 3-1/8" (77.8mm) 1-7/16" (35.7mm) 1-7/8" (46.8mm) 1-13/16" (45mm) 1-3/4" (43.9mm) 2-5/16" (58.5mm) 1-13/16" (45mm) 1-13/16" (44.6mm) 3-1/8" (77.8mm) 13/16" (20mm)
Russian
Danish
6-1/2" (160 mm)
koaksial bilhøjttaler
6" x 9" 3-vejs
koaksial bilhøjttaler
3-1/2" (87 mm)
koaksial bilhøjttaler
4" (100 mm)
koaksial bilhøjttaler
5-1/4" (130 mm)
koaksial bilhøjttaler
4" x 6" koaksial
bilhøjttaler
6" x 8" koaksial
bilhøjttaler
5-1/4" (130 mm)
komponent
højttalersystem
6-1/2" (160 mm)
komponent
højttalersystem
6" x 9" komponent
højttalersystem
3/4" (19 mm)
komponent diskant
SPESIFIKASI CLUB 6520 CLUB 9630 CLUB 3020 CLUB 4020 CLUB 5020 CLUB 6420 CLUB 8620 CLUB 5000C CLUB 6500C CLUB 9600C CLUB 750T
Tipe
Penanganan daya kontinu 50W 80W 20W 30W 40W 35W 55W 55W 60W 90W 45W
Penanganan daya puncak 150W 240W 60W 90W 120W 105W 165W 165W 180W 270W 135W
Respons frekuensi 55Hz-20KHz 50Hz-20KHz 90Hz - 20kHz 75Hz - 20kHz 75Hz - 20kHz 75Hz-20KHz 65Hz - 20kHz 70Hz-20KHz 55Hz - 20kHz 50Hz - 20kHz 3kHz - 20kHz
Impedansi Nomimal 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms
Sensitivitas (2,83V/1m) 92dB 93dB 89dB 90dB 91dB 91dB 93dB 91dB 92dB 93dB 92dB
Diameter eksternal 6-1/4" (158mm) 9-5/16" X 6-7/16" 3-7/16" (87mm) 4-1/16" (102.4mm) 5-1/8" (129mm) 6-3/16" X 3-15/16" 8-11/16" X 5-5/8" 5-1/8" (129mm) 6-1/4" (158mm) 9-5/16" X 6-7/16 2-1/4" (56mm)
(236.5mm X 163mm) (157mm X 99.5mm) (220mm X 142.2mm) (236.5mm X 163mm)
Diameter potongan dudukan 4-7/8" (123.4mm) 8-1/2" X 5-3/4" 3" (75.5mm) 3-11/16" (92.1mm) 4-1/2" (113.6mm) 5-9/16" X 3-3/8" 7-1/4" X 5" 4-1/2" (113.6mm) 4-7/8" (123.4mm) 8-1/2" X 5-3/4" 1-5/8" (40mm)
(214.6mm X 144.6mm) (140.4mm X 85.1mm) (182.6mm X 125.6mm) (214.6mm X 144.6mm)
Kedalaman total 2-1/4" (56.4mm) 3-11/16" (92.7mm) 1-7/8" (47.6mm) 2-1/8" (52.6mm) 2-1/16" (52mm) 2" (50.7mm) 2-11/16" (67.3mm) 2-1/16" (52mm) 2-1/4" (56.4mm) 3-1/2" (88mm) 1-7/16" (36.1mm)
Kedalaman dudukan 1-13/16" (44.6mm) 3-1/8" (77.8mm) 1-7/16" (35.7mm) 1-7/8" (46.8mm) 1-13/16" (45mm) 1-3/4" (43.9mm) 2-5/16" (58.5mm) 1-13/16" (45mm) 1-13/16" (44.6mm) 3-1/8" (77.8mm) 13/16" (20mm)
Speaker mobil koaksial
6-1/2" (160mm)
Speaker mobil koaksial
3-1/2" (87mm)
Speaker mobil koaksial
4" (100mm)
Speaker mobil koaksial
5-1/4" (130mm)
Speaker mobil koaksial
4" x 6"
Speaker mobil koaksial
6" x 8"
Sistem speaker
komponen 5-1/4"
(130mm)
Sistem speaker
komponen 6-1/2"
(160mm)
Sistem speaker
komponen 6" x 9"
Tweeter komponen 3/4"
(19mm)
Speaker mobil tiga jalur
6" x 9"
Bahasa
规格 CLUB 6520 CLUB 9630 CLUB 3020 CLUB 4020 CLUB 5020 CLUB 6420 CLUB 8620 CLUB 5000C CLUB 6500C CLUB 9600C CLUB 750T
類型
連續的功率處理 50W 80W 20W 30W 40W 35W 55W 55W 60W 90W 45W
峰值的功率處理 150W 240W 60W 90W 120W 105W 165W 165W 180W 270W 135W
頻率回應 55Hz-20KHz 50Hz-20KHz 90Hz - 20kHz 75Hz - 20kHz 75Hz - 20kHz 75Hz-20KHz 65Hz - 20kHz 70Hz-20KHz 55Hz - 20kHz 50Hz - 20kHz 3kHz - 20kHz
標稱阻抗 3.0ohms
3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms
敏感度 (2.83V/1m) 92dB 93dB 89dB 90dB 91dB 91dB 93dB 91dB 92dB 93dB 92dB
外徑 6-1/4" (158mm)
9-5/16" X 6-7/16" 3-7/16" (87mm) 4-1/16" (102.4mm) 5-1/8" (129mm) 6-3/16" X 3-15/16" 8-11/16" X 5-5/8" 5-1/8" (129mm) 6-1/4" (158mm) 9-5/16" X 6-7/16 2-1/4" (56mm)
(236.5mm X 163mm)
(157mm X 99.5mm) (220mm X 142.2mm) (236.5mm X 163mm)
安裝開孔直徑 4-7/8" (123.4mm) 8-1/2" X 5-3/4" 3" (75.5mm) 3-11/16" (92.1mm) 4-1/2" (113.6mm)
5-9/16" X 3-3/8" 7-1/4" X 5" 4-1/2" (113.6mm) 4-7/8" (123.4mm) 8-1/2" X 5-3/4" 1-5/8" (40mm)
(214.6mm X 144.6mm)
(140.4mm X 85.1mm) (182.6mm X 125.6mm) (214.6mm X 144.6mm)
總深度 2-1/4" (56.4mm) 3-11/16" (92.7mm) 1-7/8" (47.6mm) 2-1/8" (52.6mm) 2-1/16" (52mm) 2" (50.7mm) 2-11/16" (67.3mm) 2-1/16" (52mm) 2-1/4" (56.4mm) 3-1/2" (88mm) 1-7/16" (36.1mm)
安裝深度 1-13/16" (44.6mm) 3-1/8" (77.8mm) 1-7/16" (35.7mm) 1-7/8" (46.8mm) 1-13/16" (45mm) 1-3/4" (43.9mm) 2-5/16" (58.5mm) 1-13/16" (45mm) 1-13/16" (44.6mm) 3-1/8" (77.8mm) 13/16" (20mm)
6-1/2"(160mm)
同軸汽車喇叭
6"x 9"
三路汽車喇叭
3-1/2"(87mm)
同軸汽車喇叭
4"(100mm)
同軸汽車喇叭
5-1/4"(130mm)
同軸汽車喇叭
4"x6"
同軸汽車喇叭
6"x8"
同軸汽車喇叭
5-1/4"(130mm)
元件喇叭系統
6-1/2"(160mm)
元件喇叭系統
6"x 9"
元件喇叭系統
3/4"(19mm)
元件高音喇叭
TEKNIK ÖZELLIKLER CLUB 6520 CLUB 9630 CLUB 3020 CLUB 4020 CLUB 5020 CLUB 6420 CLUB 8620 CLUB 5000C CLUB 6500C CLUB 9600C CLUB 750T
Tip
Sürekli güç kullanımı
50W 80W 20W 30W 40W 35W 55W 55W 60W 90W 45W
Tepe güç kullanımı
150W 240W 60W 90W 120W 105W 165W 165W 180W 270W 135W
Frekans yanıtı
55Hz-20KHz 50Hz-20KHz 90Hz - 20kHz 75Hz - 20kHz 75Hz - 20kHz 75Hz-20KHz 65Hz - 20kHz 70Hz-20KHz 55Hz - 20kHz 50Hz - 20kHz 3kHz - 20kHz
Nominal Empedans
3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms 3.0ohms
Hassasiyet (2,83V/1m)
92dB 93dB 89dB 90dB 91dB 91dB 93dB 91dB 92dB 93dB 92dB
Dış çap
6-1/4" (158mm) 9-5/16" X 6-7/16" 3-7/16" (87mm) 4-1/16" (102.4mm) 5-1/8" (129mm) 6-3/16" X 3-15/16" 8-11/16" X 5-5/8" 5-1/8" (129mm) 6-1/4" (158mm) 9-5/16" X 6-7/16 2-1/4" (56mm)
(236.5mm X 163mm) (157mm X 99.5mm) (220mm X 142.2mm) (236.5mm X 163mm)
Montaj kesme çapı
4-7/8" (123.4mm) 8-1/2" X 5-3/4" 3" (75.5mm) 3-11/16" (92.1mm) 4-1/2" (113.6mm) 5-9/16" X 3-3/8" 7-1/4" X 5" 4-1/2" (113.6mm) 4-7/8" (123.4mm) 8-1/2" X 5-3/4" 1-5/8" (40mm)
(214.6mm X 144.6mm)
(140.4mm X 85.1mm) (182.6mm X 125.6mm) (214.6mm X 144.6mm)
Toplam derinlik
2-1/4" (56.4mm) 3-11/16" (92.7mm) 1-7/8" (47.6mm) 2-1/8" (52.6mm) 2-1/16" (52mm) 2" (50.7mm) 2-11/16" (67.3mm) 2-1/16" (52mm) 2-1/4" (56.4mm) 3-1/2" (88mm) 1-7/16" (36.1mm)
Montaj derinliği
1-13/16" (44.6mm) 3-1/8" (77.8mm) 1-7/16" (35.7mm) 1-7/8" (46.8mm) 1-13/16" (45mm) 1-3/4" (43.9mm) 2-5/16" (58.5mm) 1-13/16" (45mm) 1-13/16" (44.6mm) 3-1/8" (77.8mm) 13/16" (20mm)
Traditional
Chinese
Turkish
6-1/2" (160mm)
koaksiyel araba
hoparlörü
6" x 9" üç yollu
araba hoparlörü
3-1/2" (87mm)
koaksiyel araba
hoparlörü
4" (100mm)
koaksiyel araba
hoparlörü
5-1/4" (130mm)
koaksiyel araba
hoparlörü
4" x 6" koaksiyel
araba hoparlörü
6" x 8" koaksiyel
araba hoparlörü
5-1/4" (130mm)
bileşen hoparlör
sistemi
6-1/2" (160mm)
bileşen hoparlör
sistemi
6" x 9" bileşen
hoparlör sistemi
3/4" (19mm)
bileşen tweeter
2016
2016
TR01611_A
Stiahnuť návod v slovenčine (PDF, 7.17 MB)
(Myslite ekologicky a návod si vytlačte, len ak je to naozaj potrebné)
Loading…
Hodnotenie
Dajte nám vedieť svoj názor na JBL Club 4020 Reproduktor do auta a ohodnoťte výrobok. Chcete sa podeliť o svoje skúsenosti s týmto výrobkom alebo sa niečo spýtať? Napíšte komentár v spodnej časti stránky.Viac o tomto návode
Chápeme, že je pekné mať k svojmu JBL Club 4020 Reproduktor do auta papierovú príručku. Návod si môžete kedykoľvek stiahnuť z našej webovej stránky a vytlačiť si ho sami. Ak chcete mať originálnu príručku, odporúčame vám kontaktovať JBL. Mohli by byť schopní poskytnúť originálny návod. Hľadáte príručku k svojmu JBL Club 4020 Reproduktor do auta v inom jazyku? Vyberte si preferovaný jazyk na našej domovskej stránke a vyhľadajte číslo modelu, aby ste zistili, či ho máme k dispozícii.
Technické údaje
| Značka | JBL |
| Model | Club 4020 |
| Kategória | Reproduktory do auta |
| Typ súboru | |
| Veľkosť súboru | 7.17 MB |
Všetky príručky pre JBL Reproduktory do auta
Ďalšie príručky od Reproduktory do auta
Zapojte sa do diskusie o tomto výrobku
Tu sa môžete podeliť o to, čo si myslíte o JBL Club 4020 Reproduktor do auta. Ak máte otázku, najprv si pozorne prečítajte návod. Vyžiadanie manuálu je možné vykonať pomocou nášho kontaktného formulára.
