6 GB

Introduction / Safety information

Introduction

Arc welder PESG 120 A1

Introduction

Congratulations! You have chosen a

high-quality device from our company.

Familiarise yourself with the product

before using it for the first time. In addition, please

carefully refer to the operating instructions and the

safety advice below. Initial operation of this tool

must be performed by trained personnel.

KEEP OUT OF THE REACH OF CHILDREN!

Intended use

This electric welding equipment is suitable for

manual arc welding using the appropriate coated

electrodes. Improper product handling can be dan-

gerous to persons, animals and objects. Only use

the welding shield with welding glass and protec-

tive glass overlay marked accordingly, and only for

welding. The welding shield is not suitable for laser

welding! Only use the product as described and

for the indicated purpose. Keep these instructions in

a safe place. When passing this product on to others,

please also include all the documents. Any use other

than the intended is prohibited and potentially dan-

gerous. Damages resulting from noncompliance or

misuse are not covered by the warranty and are not

included in the manufacturer‘s liability. This device

has been designed for household use and may not

be used for commercial or industrial purposes.

Parts description

Electric Welding Equipment

1

Handle

2

ON / OFF switch

3

Hand wheel

4

Earth terminal

5

Brush

6

Electrode holder

7

Overheating control lamp

Welding shield

8

Welding shield

9

Handle

10

Protective glass

Symbols / Technical Data

EN 60974-6 European standard on welding

equipment for manual arc welding

with limited duty cycle

50 Hz Mains frequency

U1 Mains voltage

I1 max maximum mains current rated value

U

0

Rated no-load voltage

I

2

Welding current

φmm Electrode diameter

I

1eff

Effective value of the highest mains

current (A)

t

w

(S) Average duty cycle (s)

t

r

(S) Average reset time (s)

IP21S Protection type

H Insulation class

Power input; phase number, as well as

1

~

50 Hz alternating current symbol and

rated value of the frequency

Do not dispose of electrical equip-

ment in the household waste. In ac-

cordance with European Directive

2002 / 96 / EC covering waste

electrical and electronic equipment

and its transposition into national

legislation, worn out electrical

103333_Elektro-Schweissgeraet_content_PL_HU_SI_CZ_SK.indd 6 06.11.14 15:09
