Technical Characteristics

Dimensions (HxLxW) 21 x 26,5 x 5 cm

Weight : 0.7 kg

Working voltage : 220V-240V~, 50Hz

Power rating : 220W

Temperature : 120-220°C

Regulation : Thermostat

Glue sticks: Rapid Ø 12mm

Safety Instructions

Read safety rules and

instructions carefully

before using this

machine.

•Thisappliancecanbeusedby

children aged from 8 years and

above and persons with reduced

physical, sensory and mental

capabilities or lack of experience

and knowledge if they have been

given supervision or instruction

concerning use of the appliance

in a safe way and understand

the hazards involved. Children

shall not play with the appliance.

Cleaning and user maintenance

shall not be made by children

without supervision.

•Donotuseorstorethismachine

in a humid environment. Do

not place it where it may be

splashed by water. Do not

expose it to extreme changes in

temperature during or directly

after use.

•Onlyuseitindoorsonaclean,dry

work surface. Excessive dust and

dirt may reduce lifetime of this tool.

•Neverunplugthemachineby

pulling the cable.

•Ifthepowercableisdamaged

or cut, remove the plug from the

electric socket immediately and

do not use the machine. It must

be replaced by the manufacturer

or its service agent or a similar

qualified person in order to avoid

a hazard.

•Unplugthemachinewhennot

in use, before any servicing

operations (maintenance,

cleaning etc.)

•Alwaysverifythattheappliance

is attached to a ground socket.

•Whenusinganelectric

extension cable, check that it is

in good working order and that it

has a ground socket.

•Neverusethetoolifitis

damaged in any way.

•Neverinsertobjectsotherthan

Ø12mm Rapid glue sticks into

the machine.

•Neverremoveagluestickthat

has already been inserted.

•Itisnormalforthistoolto

become quite warm during use.

This is normal and does not

indicate a problem.

•HotSurfaces:thenozzleof

the appliance and the glue can

reach a temperature of approx.

230°C. Do not touch the heated

nozzle or the hot adhesive. Avoid

any contact with the skin. If you

burn yourself, put the burn in

cold water immediately. Never

try to remove a large quantity of

glue without medical help.

•Keepchildrenaway.Children

should not use this glue gun.

•Whenapplyingataheight,take

all the necessary precautions to

ensure that the glue does not

run onto the operator or onto

any object. Make sure that you

have enough protection wear

(skin, eyes)

•Somematerialsareheat-

sensitive and can be damaged

by the hot nozzle or even the

hot glue. Whenever possible,

test a piece of scrap material or

a hidden portion of the object

being repaired.

•Stayalert.Payattentiontoyour

work. Beware of any dripping

hot glue from your project. Use

common sense. Do not operate

this gun when you are tired. Do

not operate under the influence

of alcohol or other drugs

that may impair your physical

abilities.

•Whenyouhavefinishedusing

the machine, unplug it and

wait until it has cooled. Never

immerse glue gun in water or

other liquids to speed cooling

process. Allow it to air cool only.

The glue gun should be stored

in a closed dry and secure place

(tool box, drawer, cupboard,

etc.).

Instructions for Use

Plug the glue gun into a suitable socket, red light on

the switch means the power is on.

• Allowthetooltoheatforapproximately3-5minutes.

Insert a glue stick in the back of the tool.

• Whenthegunisfullyheated,squeezethetrigger

slowly, until the melted material begins to flow from

the nozzle. Release the trigger to stop the glue flow.

• Setthetemperaturebuttontoadjusttheoperating

temperature between 120-220° C.

• Workwithglueguntriggertoadjusttheoutputand

speed of the glue stick.

• Tochangethenozzle,thegluegunshouldbeslightly

warm but unplugged.

• Unscrewthenozzleusinggloves.

Breakdowns and remedies

• Topreventthecloggingofthisgluegun,

keep feeding mechanism and melt chamber

free from dirt and other foreign debris.

• Storeunusedgluesticksinaclean

environment.

• Donotpullgluestickfromthebackoftheglue

gun. The feed mechanism may be damaged or

impaired. If you need to change glue type, cut off the

protruding end and feed the remainder through with

the new glue stick.

• Donotlaytheheatedgunonitsside.Keepthe

heated gun in an upright position, on the metal

stand or workbench, with nozzle pointed down.

• Ifmeltedgluehasescapedfromthemeltchamber

entrance and is interfering with the feed mechanism;

allow gun to cool, and gently remove the obstructing

glue.

• Replacethenozzleifgluedripsexcessively.Donot

attempt to change the nozzle when glue is cold. To

change the nozzle, the gun must be heated until the

glue is softened enough to remove the nozzle (about

1 minute). Use gloves and remove the old nozzle.

Flush glue through the gun, to clean out the melting

chamber. Replace with a new nozzle. Tighten only

until snug. Do not over tighten.

• Keepoutsideofgluegunclean.

• Donotusegluesotherthanthoserecommendedby

Rapid

• Leavingthetoolswitchedonfortoolongwithout

use can lead to risks. Unnecessary overheating over

a long period of inactivity, without use, depending on

the length of time and type of glue used, can have

adverse effects:

* Melting and softening of the glue stick at the

back of the tool, or even adhesion of the stick

in the back entrance sleeve at the entrance of

the heater. In this case, restarting your tool for

subsequent operation may take longer and be

more difficult.

In the event of such a problem, Rapid

recommends that you follow these steps:

- Plug in the tool and leave it heating for around

fifteen minutes.

- Start to push the glue by pressing lightly on

ELECTRIC HOT MELT APPLICATOR: EG340

Operating instructions

Temperature control Changing Nozzle
