1. Connect the machine to the mains by inserting the
power supply plug in the proper outlet;
2. Switch on the machine by pulling the “ON-OFF”
switch in pos. “ON (I)” (the machine works until the
max. operation pressure of 10 bar is reached, then
it stops automatically);
3. Adjust pressure at output using the proper
regulator, according to the used tool and to the
type of processing. Check pressure in the proper
pressure gauge ;
4. Connect the tool to the air tube (extension);
5. Connect the air tube (extension) to the fast air
outlet tap of the machine;
It is strictly forbidden to use air tubes (extensions),
ttings, and tools not suitable and/or not
complying with the regulations in force.
It is compulsory to use air tubes (extensions),
ttings, and tools, complying with the provisions
It is strictly forbidden to commission the machine in
environments with potentially explosive atmosphere
and/or in presence of combustible dusts (ex: wood
dusts, ours, sugars and middlings).
COMMAND DEVICES
They are shown
1.
Power supply cable
2.
Pressure switch
3.
“ON-OFF” switch
4.
Pressure regulator at output
5.
Fast air outlet tape
6.
Pressure gauge at output
7.
Tank pressure gauge
CHECKS BEFORE SWITCHING ON
Before switching-on of the machine, the
authorized operators must compulsory
perform the following checks.
1. Make sure that there are not any non-authorized persons
close to the machine.
2. Make sure that the safety devices are integral and properly
installed and working .
3. Make sure that the machine is properly positioned .
4. Make sure that the “ON-OFF” switch or selector is positioned
on “OFF (0)”.
5. Make sure that the condensate drain valve is closed .
6. Use the compulsory personal protection devices (PPE) .
7. Make sure that you have read and understood the “Use and
Maintenance Instructions ” in all its parts.
MACHINE SWITCHING ON
The authorized operators can switch on
the machine only after having compulsorly
performed the checks described.
Before using this machine, the authorized operators
must read and understand this manual in all its part.
During the use, it is compulsory to verify that non-
authorized people do not get close to the machine.
The authorized operators are not allowed
to let the machine unattended during
operation and maintenace interventions.
Hazard of burning by accidental contact with the
bi-cylindrical pumping assembly and the electric
motor. Caution! There is a residual risk.
The manufacturer declines all liability for
damages to persons, animals and things,
due to the inobservance of the standards
and warnings described in this manual.
The manufacturer declines all liability on the nal
result of the processing given that it depends
expends exclusively on the type of tool used and on
the professional skils of the authorized operators.
2 3 4 5
1
7 8
USE LIMITS
This machine was designed and produced exclusively for the
intended use described in par.9 , any other use and operation
is therefore absolutely forbidden in order to assure in every
moment the safety of the charged operators, as well as the
efciency of machine itself.
It is forbidden to screw the pressure regulator at
output. Beyond the end of stroke, in order to avoid
damaging the membrane.
Limitations in use: it is strictly forbidden to use
the machine for improper used, differing from the
foreseen use (par.9).
It is compulsory to keep the machine out of the reach
of children.
During the use, it is compulsory to verify that non-
authorized people do not get close to the machine.
It is strictly forbidden to use air tubes (extensions),
ttings, and tools not suitable and/or not complying
with the regulations in force.
It is strictly forbidden to life the machine with cranes
and/or fork lift trucks.
It is strictly forbidden to direct compressed air jets
against persons, animals and things.
It is strictly forbidden to use the machine to transport
and/or lift persons, animals and things.
It is strictly forbidden to get on the machine.
It is strictly forbidden to tow the machine by any
means and/or vehicle whatsoever.
It is strictly forbidden to move the machine manually
on upwards and/or downwards slopes with
hazardous grade.
Hazard of burning by accidental contact with the
bi-cylindrical pumping assembly and the electric motor.
Caution! There is a residual risk.
6
EN
