6 | English

1 609 92A 2PD | (30.8.16) Bosch Power Tools

English

Safety Notes

General Safety Rules

Read all warning notes and instructions en-

closed with the magazine attachment. Fail-

ure to follow the warnings and instructions

may result in electric shock, fire and/or serious

injury.

Save all safety warnings and all instructions for future ref-

erence.

Safety Warnings for Magazine Attachments

 Pull the plug from the mains receptacle and/or remove

the battery from the power tool before making adjust-

ments on the tool or changing tool accessories. Unin-

tentional switching on of the power tool is the cause of

many accidents.

 Hold the machine with a firm grip. High reaction torque

can briefly occur while driving in and loosening screws.

 Secure the workpiece. A workpiece clamped with clamp-

ing devices or in a vice is held more secure than by hand.

 Always wait until the machine has come to a complete

stop before placing it down. The tool insert can jam and

lead to loss of control over the power tool.

 Dress properly. Do not wear loose clothing or jewel-

lery. Keep your hair, clothing and gloves away from

moving parts. Loose clothes, jewellery or long hair can be

caught in moving parts.

 Never direct the machine at yourself or at persons

close by.

 While working, never reach into the magazine attach-

ment and keep your hand clear of the spot, where you

are driving in the screw. Danger of injury from crush-

es/contusions or sharp-edged screws.

 Use only suitable screw strips according to the techni-

cal data. When using other screws, the magazine attach-

ment can become damaged.

 Before any work on the machine (e. g., maintenance,

tool change, etc.) as well as during transport and stor-

age, set the rotational direction switch to the centre

position. Unintentional actuation of the On/Off switch can

lead to injuries.

Product Description and Specifica-

tions

Intended Use

The magazine attachment is intended for efficient driving-in

of drill screws, particle board screws, and wood construction

screws. The magazine attachment may only be used with the

following cordless drill/drivers:

– GSR 6-25 TE (3 601 D45 0..)

– GSR 6-45 TE (3 601 D45 1..)

– GSR 18 V-EC TE (3 601 JC8 0..)

– GSR 10,8 V-EC TE (3 601 JE4 0..)

Product Features

The numbering of the product features refers to the illustra-

tion of the magazine attachment on the graphics pages.

1 Screwdriver bit with ball catch

2 Tool holder

3 Screw stop

4 Screw strip*

5 Pin for adjustment of screw length

6 Knurled thumbwheel for screw-in depth

7 Scale for screw-in depth

*Accessories shown or described are not part of the standard de-

livery scope of the product. A complete overview of accessories

can be found in our accessories program.

Technical Data

Assembly

 Before any work on the machine itself, pull the mains

plug.

Mounting the Magazine Attachment

Pull off the drill/driver’s standard depth stop, if mounted.

If a standard bit holder is mounted, pull it off toward the front.

You can use an auxiliary tool to remove the bit or bit holder.

Insert the special screwdriver bit 1 into the tool holder 2 of

the drill/driver.

Slide the magazine attachment over screwdriver bit 1 to the

stop on the motor housing.

The magazine attachment can be mounted off-set in 45°

steps in order to achieve a safe and low-fatigue working

stance.

Inserting a Screw Strip (see figure A)

 Insert the screw strip only when the power tool is

switched off.

Slide screw strip 4 toward the front through the strip guide

until the first screw is seated one engaging step behind the

screw stop centre 3.

Magazine attachment MA 55

Article number

1 600 Z00 00Y

Screw dimensions

– Screw length

– Shank diameter, max.

–Diameter of screw head,

max.

mm

mm

mm

25–55

5

9.5

Weight, approx.

kg 0.36

OBJ_BUCH-1437-004.book Page 6 Tuesday, August 30, 2016 12:21 PM
