Návod Crivit IAN 271523 Kolieskové korčule

Návod

GB/IE

3

Congratulations!

With your purchase you have decided on a high-

quality product. Get to know the product before you

start to use it. Carefully read the following assembly

instructions. Use the product only as described and

only for the given areas of application. Keep these

instructions safe. When passing the product on to a

third party, always make sure that the documentation is

included.

Please note that you have purchased a product intend-

ed for normal, private home use. These inline skates

are produced as fitness skates for private use and are

not suitable for street hockey or other aggressive forms

of skating.

In order that you can enjoy this product for a long time,

please observe the following instructions of use and

care information.

Designation

Junior Inline Skates

Scope of supply

1 pair of Junior Inline Skates

1 x User Manual

1 x replacement stopper

2 x Allen key

Technical sp

e-

cifications

Sizes: 35

-

39

Tested in accordance with EN

13843, Class A, 20 - 100 kg

Wheels: 80 x 22 mm

Ball bearings: ABEC 7

Explanation of

Figure A

#1 Notched strap

#2 Rocker/push buckle

#3 Latching mechanism safety

cover

#4 Safety latching mechanism

#5 Power Strap Velcro fasten-

er

#6 Laces

#7 Loops to help pull on the

skates

#8 Pushbutton for size adjust-

ment

#9 Set shoe size indicator

Warning: Important safety & general inform

Warning: Important safety & general informWarning: Important safety & general inform

Warning: Important safety & general informa-

a-a-

a-

tion

tiontion

tion

 Please adhere to this user manual and keep it in a

safe place!

 Always be aware of other road users and follow the

highway code.

 Select an appropriate surface for inline skating.

Surfaces should be smooth, clean and dry.

 Prior to skating check that all screws and nuts are

securely fastened.

 Make sure that screws and nuts retain their self-

locking properties.

Warning: The effectiveness of

self-locking screws and fixing elements can de-

crease over time. Therefore, you should replace the-

se screws at appropriate intervals.

 Do not modify your inline skates in such a way as

they might pose a risk to your safety under certain

circumstances.

 Remove sharp edges that can develop while skat-

ing.

 Always wear suitable protective

equipment consisting of a helmet,

palm, wrist, elbow and knee protec-

tors.

 Avoid areas with heavy traffic.

 Always remain alert and exercise caution.

 Avoid skating at excessive speed. Rule of thumb:

Never skate faster than you can run.

 Regularly replace the brakes, wheels and ball bear-

ing if they become worn.

 Always wear reflective clothing to make you more

visible.

 Do not wear the skates without socks.

General information

General informationGeneral information

General information

Inline skating is a high-risk sport. The risks involved can

be reduced by wearing protective equipment and skat-

ing carefully. You should always perform checks your-

self to increase the level of protection against injury.

1. You should check the equipment each time before

you skate. This includes checking that the axles and

wheels are secure, and checking the wheels and

stoppers for wear. If necessary, tighten the screws

and nuts with the standard tool provided.

2. To put the skates on, untie the laces and release the

buckle (fig. B – D). Then pull the inline skates on

with the help of the loops (7, fig. E). Ties the laces

(6) and fasten the Velcro fastener (5). Push the

notched strap (1) into the opening beneath the

rocker/push buckle (2) and adjust to the appropri-

ate tension (Fig. F). Close the quick-release fastener

(4) until you hear an audible CLICK. After closing,

your foot must be securely held inside the skates.

This is important if you are to maintain control when

skating. The outer shoe should not distort when clos-

ing the quick-release fastener. Do not close it with

force.

3. To take the skates off, push the pressure slider (3) of

the quick-release fastener (4) in the direction of the

arrow and open the quick-release fastener (Fig. B).
