ENDaily Reference Guide

1

THANK YOU FOR BUYING AWHIRLPOOL PRODUCT.

In order to receive amore complete assistance, please

register your appliance on: www.whirlpool.eu/register

W11553946 panel 2023-01-17

W11572189 button R 2021-10-01

W11572083 button L 2022-02-15

W11569647 display 2023-02-17

1 2 3 4 5 6 7 8 9 10

11 12 13

14

15

P

3 sec.

21

65°

3 4 5 6 7 8 9 10

50 °

Eco

65°

A

55°

A

50°

A

45°

65°

SELF CLEAN

Before using the appliance carefully read Safety

and Installation Instructions. More information about your product

available on website: docs.whirlpool.eu/docs

After installation, please remember to remove all transport protection

parts from the dishwasher.

CONTROL PANEL

1. ON-OFF/Reset button with indicator light

2. PREVIOUS program button

3. NEXT program button

4. FAVOURITE program button with indicator light

5. Salt reservoir empty indicator light

6. Rinse Aid reservoir empty indicator light

7. DESCALE indicator light

8. Closed Water Tap indicator light

9. Display

10. Program number and remaining time indicator

11. Power Clean® option button with indicator light

12. Half Load option button with indicator light/ Settings - 3 sec. press

13. Extra Dry option button with indicator light

14. Delay option button with indicator light

15. START/Pause button with indicator light

FIRST TIME USE

SETTING MENU

1. Switch on the appliance by pressing the ON-OFF button.

2. Hold the Settings (Half Load ) button for 3 seconds, until you hear

abeep and the display shows „SEt”.

3. After one second the rst available setting (letter „h”) will be displayed.

4. Press PREVIOUS /NEXT to scroll through the list of available settings

(see table below), then press START/Pause to view and change the

value of the currently selected setting.

5. Press PREVIOUS /NEXT to change the value, then press START/Pause

to save the new value and return to the main menu.

6. To change another setting, repeat points 4 and 5.

7. Press ON-OFF or wait 30 seconds to exit the menu.

LETTER

SETTING

VALUES

(Default - in bold)

Water Hardness Level

(see “SETTING THE WATER HARDNESS”

and “WATER HARDNESS TABLE”)

1 | 2 | 3 | 4 | 5

Rinse Aid Level

(see “ADJUSTING THE DOSAGE OF RINSE AID”)

0 | 1 | 2 | 3 | 4 | 5

NaturalDry (see “OPTIONS AND FUNCTIONS”)

“1” = On, “0” = O

1 | 0

Light on the oor

(see “OPTIONS AND FUNCTIONS”)

“1” = On, “0” = O

1 | 0

Sound

“1” = On, “0” = O

1 | 0

Factory Settings

Press START/Pause to restore to the factory

default all the values of the settings included

in the settings menu.

-

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes and on

the machine’s functional components.

The salt reservoir is located in the lower part of the dishwasher (under the

lower rack on the left side).

• It is mandatory that the salt reservoir never be empty.

• It is important to set the water hardness.

• Salt must be lled when the SALT REFILL indicator light on the con-

trol panel is lit.

1. Remove the lower rack and unscrew the reservoir cap

(anticlockwise).

2. Position the funnel (see gure) and ll the salt reservoir

right up to its edge (approximately 0,5 kg); it is not un-

usual for alittle water to leak out.

3. Only the rst time you do this: ll the salt reservoir

with water.

4. Remove the funnel and wipe any salt residue away from the opening.

Make sure the cap is screwed on tightly so that no detergent can get into

the container during the wash program (this could damage the water sof-

tener beyond repair).

Run aprogram every time as soon as you completed relling the salt

reservoir to avoid corrosion.

Setting the water hardness

To allow the water softener to work in aperfect way, it is essential that the

water hardness setting is based on the actual water hardness in your house.

This information can be obtained from your local water supplier. The facto-

ry setting is “3”. See „WATER HARDNESS TABLE”.

To change, follow instructions in section “SETTING MENU”.

Only use salt that has been specically designed for dishwashers.

After the salt has been poured into the machine, the SALT REFILL indicator

light switches o. If the salt container is not lled, the water softener and

the heating element may be damaged as aresult of limescale accumula-

tion. Use of salt is recommended with any type of dishwasher detergent.

Water Hardness Table

Level

°dH

German degrees

°fH

French degrees

°Clark

English degrees

1 (soft) 0 - 6 0 - 10 0 - 7

2 (medium) 7 - 11 11 - 20 8 - 14

3 (average) 12 - 16 21 - 29 15 - 20

4 (hard) 17 - 34 30 - 60 21 - 42

5 (very hard) 35 - 50 61 - 90 43 - 62

WATER SOFTENING SYSTEM

Water softener automatically reduces water hardness, consequently pre-

venting scale buildup on the heater, contributing also to better cleaning ef-

ciency. This system regenerates itself with salt, therefore it is required

to rell the salt container when empty. The frequency of regeneration

depends on the water hardness level setting - regeneration takes place

once per 4-6 Eco cycles with the water hardness level set to 3. During runs

with regeneration, additional water management system ll will happen.

The regeneration and water management process occurs at the beginning

of the cycle with additional fresh water.

• Single regeneration consumes: ~7.5 of water;

• Takes up to 15 additional minutes for the cycle;

• Consumes below 0.065 kWh of energy.

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse aid dispenser Ashould be

lled when the RINSE AID REFILL indicator light in the control panel is lit.

1. Open the dispenser B by

pressing and pulling up the

tab on the lid.

2. Pour in the rinse aid (max.110

ml), making sure it does not

overow from the dispenser.

If this happens, clean the spill

immediately with adry cloth.

3. Press the lid down until you hear aclick to close it.

NEVER pour the rinse aid directly into the appliance tub.

Adjusting the dosage of rinse aid

If you are not completely satised with the drying results, you can adjust

the quantity of rinse aid used.

To change, follow the instructions in the section “SETTING MENU”.

If the rinse aid level is set to ZERO, no rinse aid will be supplied. The LOW

RINSE AID indicator light will not be lit if you run out of rinse aid.

Amaximum of 6 levels can be set according to the dishwasher model.

• If you see bluish streaks on the dishes, set alow number (0-3).

• If there are drops of water or limescale marks on the dishes, set amid-

range number (4-5).

A

B
